CSM ORCA TECH® 288 NB Black Reinforcement Sheet – Protection and Reinforcement for Floats

The ORCA® 288 Black reinforcement sheet is a professional-grade solution designed to protect, reinforce, and extend the service life of the floats on inflatable and semi-rigid boats. Made from marine-grade CSM (chlorosulfonated polyethylene), it offers exceptional resistance to abrasion, friction, and external aggressors such as UV rays, saltwater, hydrocarbons, and mechanical stress.

Developed specifically for optimal adhesion to ORCA® fabrics, this CSM sheet ensures a reliable and durable bond when used with the appropriate neoprene/CR adhesives, even on high-stress areas of the float.

Essential protection for exposed areas

ORCA® 288 sheet is ideal for reinforcing all sensitive areas of an inflatable float:

Diver access points and boarding areas
The front and lower parts of the float, which are subject to repeated friction against the pontoons
Anti-chafing reinforcements for heavy-duty mooring or coastal navigation
Protection against thorns, fishhooks, and abrasive friction, particularly for sport fishing
Areas where the boat comes into contact with mooring lines, docks, rocks, or sand

Itsblack finish gives it a discreet, professional look that blends seamlessly with black or dark floats.

Multiple thicknesses for every use

The ORCA® 288 line is available in several thicknesses, allowing you to precisely tailor the level of protection to the boat’s intended use:

0.70 mm: Lightweight reinforcement, diver passages, standard abrasion protection
1.00 mm: versatile reinforcement for high-stress areas
1.40 mm: areas subject to frequent friction, heavy-duty use
2.50 mm: enhanced protection against impacts and severe wear
3.00 mm: professional use, high-traffic areas, or work floats

One side features a non-slip textile texture, ideal for ensuring safe movement on board and improving ergonomics without compromising adhesion.

Compatibility and Implementation

Compatible with all ORCA® CSM/Hypalon® floats
Excellent adhesion when used with two-component CR neoprene adhesive
Suitable for repairs, preventive reinforcement, and customization of floats
Used by many shipyards, professional repair shops, and maritime workforces

Technical Specifications

Product: ORCA® 288 NB Black
Material: 100% marine-grade CSM
Color: Black
Available thicknesses: 0.70 / 1.00 / 1.40 / 2.50 / 3.00 mm
Finish: Smooth
Size: 1 unit = 100 × 150 cm
Application: Reinforcements and protective covers for inflatable floats
Brand: ORCA® – Pennel & Flipo
